Build reporting dashboards

A dashboard is a saved arrangement of charts that you can apply to any run. Instead of clicking through tabs every time, you open the run and the same six charts your team cares about appear in the same layout.

When to build a dashboard

• You have a recurring test and you want a one-glance health check.
• You compare runs and want the same axes every time.
• You report performance numbers to a wider audience and want a stable view.

Build a dashboard

1. Open any run in the test you want to track. Switch to the Reporting tab.



   The dashboard builder — add, filter, and arrange charts, then save the layout as a dashboard.

2. Click Add chart. Pick a chart type — line, bar, donut, or radial — and the metric to plot (latency p95, throughput, error rate, virtual users, runner health).

3. Filter the chart by request label, scenario, or location if needed.

4. Give the chart a clear title and short description so teammates know what it shows at a glance.

5. Repeat for each chart you want to pin. Drag to reorder; resize to fit your screen.

6. Save the dashboard with a name like Checkout — release review or Hourly smoke.

Templates

Once saved, a dashboard can be applied to other runs of the same test. Use the Apply dashboard menu on a run page to switch between dashboards.

You can also pin a default dashboard so every new run of the test opens with the same view.

Share a dashboard

Dashboards live at the workspace level, so any teammate who can see the run can see the dashboard. There is no separate sharing step — anyone who opens the run sees the dashboard you saved.

Start with three charts

A dashboard with twenty charts is harder to read than three well-chosen ones. Start with p95 latency by label, throughput, and error rate, then add more only when you find yourself looking somewhere else every time.

Where to go next

• Read run results and logs — what to put on a dashboard and why.
• Schedule recurring tests — combine a schedule with a default dashboard.
• Scenarios and VarioTest — dashboards work across scenarios and child runs.
